VRISS
VRISS recirculating ink supply system can be adapted to a variety of recirculating printheads,
ink recirculation can take away the impurities and air bubbles in the ink lines and nozzles,
then the nozzles are able to restore the phenomenon of missing lines by itself.
For heavy production enterprises, a stable printer that will not cause unplanned downtime is very important,
and the use of VRISS can minimize the maintenance frequency,
avoid unexpected production line pause and ensure the continued stability of marking.
Recirculating Ink Supply System
• LED Real-time status display
• 900ML Large Tank of Continuous Ink Supply
• Ink circulation, electronic inking, ink tank agitation, cartridge heating
• Low Ink Cost
• Modular design, flexible installation
• Precise pressure control
• Different printhead options
• 900ML Large Tank of Continuous Ink Supply
• Ink circulation, electronic inking, ink tank agitation, cartridge heating
• Low Ink Cost
• Modular design, flexible installation
• Precise pressure control
• Different printhead options
Specifications
| Power Input | DC 24V 5A |
| Basic Functions | Ink circulation, electronic ink priming, ink tank agitation, ink heating |
| Ink Supply | Recirculating ink supply |
| Ink Type | UV ink, Oil-based ink |
| Ink Tank Capacity | 900ml |
| Ink Tank Alarm Level | 60ml-80ml |
| Hardware Interface | 1. Power switch, 2. Power input connector, 3. USB port, 4. Electronic ink priming button, 5. PLC port, 6. External ink barrel level & agitation interface |
| Ink Path Interface | 1. Ink supply port, 2. Ink return port, 3. Safety bottle drain port |
| Negative P. range | -9999~0pa |
| Pressure Range | 0~22999pa |
| Dimension | 254*170*222 |
| Operating Environment | 23°F (-5°C) -113°F (45°C) |
| Storage Environment | -4° F (-20°C) -149°F (65°C) |
| Certifications | CE、FCC |
